Subal Nikon Z7 II, Z6 II, Z7, & Z6 Underwater Housing NZ7

With the SUBAL NZ7 for the Nikon Z6 (I & II) & Z7 (I & II), SUBAL offers Nikon cameras an aluminum housing for the latest camera.


• Maximum depth: 80m/260ft (120m on request)
• Weight: Approx. 2.5 kg (without port and accessories)
• Weight in water: nearly neutral (depending on the port and accessories)
• Dome port and accessories are shown on picture not included in housing scope of delivery!

SUBAL NZ is a new design and engineering masterpiece. Housing provides access to all functions and buttons of the Nikon Z6 & Z7 cameras. The ergonomic SUBAL design and arrangement of all important elements of the housing allow the camera an easy operation without letting go of the handle. The camera is mounted on a special sled, to mount the camera with precision in the housing, this allows a faster and secure mounting. A 4 mm O ring and the NEW SUBAL locking system, prevents accidental crushing of the O-ring and ensures maximum safety. Threaded holes at the base allow attaching Rails etc. Pilot lights can be attached or mounted to the top shoe. The monitor window provides a glare-free and high-contrast insight on the camera monitor. Material selection, processing, surface protection, and finish conform to the usual standard level of quality that is all the SUBAL products. SUBAL offers for this housing model 4 different search systems: the standard viewfinder slimmed reduces the viewfinder image, so that it can fully be viewed despite diving mask. The GS 180 and the 45° viewfinder offer a viewfinder in size approximately corresponding to the camera's viewfinder, with the insight of the GS-180 horizontally, the insight of the WS-45 under 45°. The new Prism Finder PS-30 shows the camera monitor image at the same size at a viewing angle of 30°. The insight is with normal reading distance, which is why the PS-30 is ideal for video recording that Nikon D5 have in 4K resolution. All Subal viewfinders systems are interchangeable and can be mounted easily by the user. All SUBAL ports with bayonet mount on this case can be used.

Also, this housing has a plug-in system for installing the camera into housing - there is no need for any setting of the camera before putting it into housing. With this self-adjusting system with springs, the only thing that customer should do is to fix the camera on the camera tray and to slide it into housing.


Technical data:

Seawater resistant aluminum alloy worked from the block. Hard Coating and corrosion treatment are applied to the surface of the housing. In addition, 3 layers of powder coating paint are applied to give the housing the subal color and unique finish. All parts are made of hard-anodized light alloy, acid-resistant stainless steel, and high-quality plastics, to endure all working conditions. SUBAL QuickLock closure system.


Width x height x depth:

Approx. 255 x 172 x 147 mm mm (w/o port and handles)


Accessories:

• On the back side, there is a thin line for showing the middle of the objective. This is for easy positioning camera when taking photos by SPLIT technique
• 5 pin standard connectors
• optical connector optional
• Nikon TTL system optional for Sea&Sea & Inon strobes
• 16mm thread for vacuum sensor and remote control system
• installed electronic leaking alarm
• ability to install SUBAL manual trigger
• the ability for using all underwater camera tripods.



Flash arm mounting:

2 x T-plates 25 mm, TLC - or ultralight base optional shoe, top shoe mounting
