Sea & Sea MDX-Z7 Underwater Housing for Nikon Z 7 & Z 6 Mirrorless Housings

State-of-the-art housing for the full-frame mirrorless Nikon Z7/Z6 camera. Compact, compatible with the Optical YS Converter and ergonomically designed.

Compact design.

Taking advantage of the Z7/6 camera’s compact design and lightweight, the housings have been designed accordingly to enhance these features. Compared to SLR MDX-850 camera housing, the MDX-Z7/6 is 100g/3.5oz lighter in weight on land.

Weight: MDX-Z7 2700g/95.2oz (on land), MDX-D850 2800g/98.8oz (on land).

Ports and gears for the MDX series SLR housings can be used.

The MDX-Z7/6 is compatible with the system chart for the MDX series SLR housings. You can utilize F-mount lenses with the mount adapter FTZ and ports/gears for the MDX series housings.

Compatible with Optical YS Converter/N1. TTL strobe photography possible.

An optional Optical YS Converter which converts the camera’s hot-shoe TTL signal into an LED light signal is compatible with the housing. Manual strobe photography is also possible.

Designed for both F mount lenses with the mount adapter FTZ and Z mount lenses.

The Focus/Zoom dial has two gears, one for F-mount lenses with the mount adapter FTZ and the other for Z mount lenses. The MDX-Z7 has been designed to take into consideration various Z mount lenses which will soon be available.

The camera’s upper control panel can be seen.

A window for the camera’s upper control panel is also incorporated. As the brightness of the camera’s upper control panel has increased, the visibility is now greatly improved.

MDX-Z7 Other Features

• The Port Lock prevents the port from turning or loosening and the Port Lock lever is specifically located to avoid being unlocked accidentally.
• The housing is equipped with a lens-lock release button which makes it possible to change lenses easily, without opening the housing.
• Pulling out the Focus/Zoom Dial gives sufficient room inside the housing to easily accommodate larger diameter lenses.
• The camera’s diopter adjustment dial can be operated from outside the housing. This feature is useful when two or more people with different eyesight use the housing.
• All controls have luminescence stickers which glow in a dark environment.
• Equipped with the Optical Viewfinder 0.5x as standard. Other optional viewfinders such as Optical Viewfinder 0.66x, and 0.8x can be used.
• Some vignetting occurs. When the VF45 and VF180 1.2x is mounted on the housing, the corners of the camera's viewfinder cannot be viewed due to vignetting.
• Sync Cord 2-pin Connector enables the use of conventional hardwired Sync cable (Manual mode only).
• Equipped with two sacrificial zinc diodes (one on the front case and the other on the rear) to prevent electrolysis damage.
• Equipped with under guard to protect from scratches.

Specifications

• [Construction]
• Body: corrosion-resistant aluminum alloy (machined)
• Grip: corrosion-resistant die-cast aluminum alloy
• [Depth rating] 100m / 330ft
• [Dimensions (WxHxD)] 339 x 169 x 158 mm / 13.3 x 6.7 x 6.2 inches
• [Weight] Approx. 2,700g / 95oz (Housing only)
• Equipped with two (2) Fiber-Optic Cable Sockets
• Equipped with one (1) N-Type (2-pin) connector
• Equipped with two (2) Sacrificial Zinc Diodes (front/rear)
• Built-In Leak Detector Sensor
• Compatible with SEA&SEA Strobes, Sea Arm 8, Fiber-Optic Cable II, Electronic Sync Cords, Leak Sentinel (Vacuum Pump System)
