Ikelite Nikon D500 Underwater Housing 200FL

Ikelite 200FL Underwater Housing for Nikon D500 DSLR Camera

• Four Lock (FL) Port System is compatible with legacy Ikelite standard and modular ports ports; the FL system makes it quick and easy to change lenses
• Extra-large, soft touch zoom knob; Zoom is accessible for many lenses using Ikelite's unique universal zoom gear system
• Included Ikelite ICS-5 bulkhead connector with manual hotshoe for reliable electrical triggering of underwater strobes; Optional TTL accessories provide automatic exposure with compatible Ikelite DS strobes
• Control symbols are laser etched into the back and will never fade or rub off
• Quick install camera mount plate does not need to be removed for battery or memory card access
• Two spare 1/2-20 threaded accessory port locations on the front of the housing for the addition of optional accessories
• Includes a balanced aluminum base with left-hand quick release handle; Right-hand handle sold separately
• Signature open-groove design suspends the rear o-ring in a natural position that is easier to maintain and more reliable than forcing the o-ring into a channel
• ABS-PC and Lexan construction is fundamentally corrosion-resistant
• Made in the USA; Individually inspected for fit and water pressure tested to 200' (60m)
• 1 year limited warranty

Controls Provided

• Shutter-release button
• Power switch
• Movie-record button
• Sub-command dial
• Exposure compensation (+/-) button
• ISO button
• MODE button
• WB button
• Metering button
• BKT button
• Lens release button
• AF-ON button
• Main command dial
• Multi selector
• Info button
• Live view selector
• Lv button
• i button
• Playback button
• Trash button
• MENU button
• Key/? button
• Magnify + button
• Magnify - button
• OK button
• Fn2 button

Camera Compatibility

This housing is only compatible with the Nikon D500 DSLR as shipped by the manufacturer. Unless otherwise noted, this housing does not accommodate the use of add-on grips, battery grips, eyepieces, LCD covers, or other accessories.

Differences in lens and control placement prevent other DSLR models from being used in this housing. Ikelite is not aware of any other models which may be used in or adapted to this particular housing.

Strobe Options

TTL Exposure

Install optional Nikon TTL Hotshoe Product number 46061 and connect the TTL Converter Product number 4301.3 for automatic TTL exposure with compatible Ikelite DS-model Strobes. Ikelite DS-model strobes may be used with this system without the TTL Hotshoe and Converter, but will not provide TTL exposure.

Non-Ikelite Strobes

SEA & SEA, INON, and Nikonos strobes with an electrical connection can be triggered in manual exposure modes using an electrical sync cord. Strobes without an electrical sync cord connection cannot be attached to this system unless slaved off of a hard-wired strobe.

Ikelite Non-Digital Strobes

Older non-digital strobes featuring an ICS-5 electrical sync cord bulkhead can be used with this system in manual exposure modes.

Fiber Optic

Fiber optic only strobes are not compatible with this installation. An external strobe must be connected by electrical sync cord.

Remote Triggering

Strobes with remote slave capabilities may be triggered off of a flash attached to the housing by electrical sync cord. Ikelite DS strobes support remote triggering using the Optical Slave Converter Product number 4403 or the Water Wizard system (manufactured and sold by Aquatica).

What's Included

• Underwater Housing with 200ft Back
• Base with Left-Hand Quick Release Handle # 4077.67
• Port Hole Cap # 0200.91
• Waterproof Bulkhead Cap # 9104.5
• Universal Zoom Set for Lenses Up to to 2.8" Diameter # 5509.27
• Universal Zoom Set for Lenses 2.8 to 3.0" Diameter # 5509.28
• Silicone Lubricant 1cc Tube # 0184.1
• Optional Accessories
• Right-Hand Quick Release Handle with Extension # 4077.02
• Straight Magnified Viewfinder # 6890
• 45° Magnified Viewfinder Type 1 # 6891.1
• TTL Hotshoe # 46061 + TTL Converter # 4301.3

Specifications

• 200' (60m) depth rating
• 1/4-20 thread base mounts with 3.5" spacing
• Near neutral buoyancy in fresh water
• Actual buoyancy varies depending on choice of lens and port
• Weight 5.1 lb (2.3 kg) not including tray + handles
• Dimensions 9.2 x 7.1 x 6.6" (234 x 180 x 168 mm) including projections

Spare Parts

• 0132.61 - Main o-ring
• 0105 - Port o-ring
• 9104.5 - Waterproof bulkhead cap
• 0200.91 - Housing body cap
• 0184.2 - Silicone lubricant resealable 2cc tube
