Sony E PZ 10-20mm F4 G APS-C constant-aperture power zoom G lens

• The world's smallest, lightest ultra-wide-angle constant F4 APS-C power zoom lens
• Dynamic perspectives and G Lens quality throughout the 10-20mm range
• Power zoom with variable speed lever, responsive operation, and control
• Fast, precise, quiet AF, and tracking for movies and stills with two linear motors
• Reduced focus breathing and shift while zooming for refined movie imagery
• Consistent balance for easy handling with internal focus and zoom structures
• Control zoom remotely with compatible cameras, accessories, or smart devices
• Naturally rendered bokeh and excellent close-up performance (7.9" AF)
• Linear Response MF for precise, repeatable manual focus control
• Dust and moisture-resistant design for reliability in challenging conditions
• ED and ED aspherical elements correct spherical and chromatic aberrations
• Minimum focusing distance is just 5.1" (W), 6.7" (T), 0.18 max magnification
• Instant auto/manual focus selection via AF/MF switch
• The focus hold button can be customized for various functions
• Petal-shaped, bayonet mount lens hood supplied

The smallest, lightest F4 ultra-wide APS-C power zoom

The world's smallest and lightest constant F4 ultra-wide-angle APS-C power zoom lens offers outstanding mobility and superb image quality for both stills and movies. Smooth, versatile power zoom provides speed and framing control, adding extra expression to dynamic ultra-wide visual perspectives.

The world's smallest and lightest

Just 2-1/4 in. (55 mm) long and weighing a mere 6.3 oz. (178 g), this is the world's smallest, lightest F4 ultra-wide-angle power zoom lens. Thanks to internal zoom and focus, the lens does not change in length when zooming or focusing, providing a stable center of gravity that is ideal for vlogging and gimbal-mounted shooting. Outstanding mobility makes it an excellent choice for a wide range of situations.

Dynamic perspectives and imagery

A 10 mm (35mm full-frame equivalent: 15 mm) focal length at the wide end of the zoom range provides extremely wide angles of view that can easily cover sweeping scenes or reveal more in small spaces. This versatile lens can also deliver dynamic images utilizing unique perspectives, effectively separating the subject from the background and emphasizing distance or speed in movies.

Outstanding optics in a compact lens

Three aspherical elements suppress field curvature and astigmatism, while an ED (Extra-low Dispersion) aspherical element subdues chromatic aberration for high image-wide resolution throughout the 10 to 20 mm zoom range (35mm full-frame equivalent: 15 to 30 mm). Naturally rendered G Lens bokeh can deliver striking expression with this lens's 7.9" (0.2m) minimum AF distance and 5.1 - 6.7" (0.13 - 0.17 m) minimum MF distance.

Responsive power zoom

A new electronic power zoom system instantly converts zoom ring rotation to actual zoom operation so that the creator's intent is faithfully captured. There's also a zoom lever that makes it easy to execute super-slow constant-speed zooms that are difficult with manual zoom. Zoom can also be controlled remotely from the optional GP-VPT2BT grip, RMT-P1BT remote commander, or the Imaging Edge Mobile application.

Optimized for smooth movies

Advanced lens technology reduces focus breathing, focus, and axial shift when zooming to ensure that smooth, high-quality movie footage is always captured. Unwanted, distracting changes in the angle of view and framing are minimized so the viewer can fully immerse in the imagery.

Extraordinary AF for stills and movies

Two linear motors ensure fast, quiet, low-vibration autofocus that can smoothly track subjects when shooting high frame rate movies and reliably follow fast-moving subjects when shooting stills continuously at high speed. Focus is especially critical when shooting 4K or 8K movies, particularly while zooming. This lens quickly acquires focus and tracks challenging subjects smoothly and silently.

Lens Specifications

• Lens mount: Sony E-mount
• Format: APS-C
• Maximum aperture (F): 4
• Minimum Aperture (F): 22
• Maximum Magnification ratio (x): 0.14(AF) 0.18(MF)
• Dimensions dia. x length (mm): 69.8 x 55.0
• Dimensions dia. x length (in.): 2-3/4 x 2-1/4
• Weight (approx.) (g): 178
• Weight (approx.) (oz.): 6.3
• Focal-Length (mm): 10 - 20 mm
• 35mm equivalent focal-length (APS-C) (mm): 15 - 30 mm
• Lens construction (groups-elements): 8 / 11
• Number of aperture blades: 7
• Circular Aperture: Yes
• Minimum focus distance (m): 0.20(AF) Wide:0.13/Tele:0.17(MF)
• Minimum focus distance (ft): 0.66(AF) Wide:0.43/Tele:0.56(MF)
• Filter Diameter (mm): 62
• Image stabilization (SteadyShot): - (body-integrated)
• Zoom system: Powered
• Teleconverter compatibility (x1.4): Incompatible
• Teleconverter compatibility (x2.0): Incompatible
• Hood Type: Petal shape, bayonet type
• type: Interchangeable lens
• Angle of view (APS-C) *With interchangeable-lens digital camera incorporating APS-C type image sensors.: 109°-70°

Other Information

• Mount rubber ring: Yes
• ED/Super ED glass (elements): ED
• Aspherical lens (elements): Yes
• Lens coating: Multi-coating
• Focusing type: Internal
• AF actuator: Linear motor
• Linear Response MF: Yes
• Zoom actuator: Linear
• Zoom rotation reversing: Yes
