OM System 150-400mm f/4.5 TC1.25X IS PRO M.Zuiko Digital ED lens

Announcing breakthrough technology that changes the way you shoot. The M.Zuiko 150-400mm IS PRO delivers unrivaled portability, imaging power, and all-weather performance. At only 4.1 pounds and 12.4 inches in length, you can easily hold the 35mm-equivalent 1000mm reach for unprecedented mobility. Powerful image stabilization enables sharp telephoto images, all handheld. Break free from your tripod. The ultra-zoom revolution has begun.

• 300-1000mm Focal Length (35mm equivalent)
• Constant F4.5 Aperture
• .71x Max Image Magnification
• Z Coating Nano
• Large Diameter EDA Lens
• Fluorine Protective Lens Coating
• Splashproof, Dustproof, Freezeproof Construction
• Heat Resistant Exterior
• In-lens Image Stabilization
• AF / MF Switch
• Preset Focus
• AF Limiter
• Built-in 1.25x Teleconverter
• 1.4x & 2.0x Teleconverter Compatible

SUPER TELEPHOTO POWER IN A COMPACT SIZE

Capture richly detailed images with the powerful ultra-telephoto Lens you can comfortably hold in your hand.

Powerful Focal Range

Reach far with a powerfully small lens. The compact 150-400mm IS PRO Lens delivers a 35mm equivalent focal range of 300-800mm that gets you close without moving a step, and the built-in teleconverter can extend your reach even further. It's so powerful that you can easily capture the minute detail on a bird's wing or the whiskers on a fox.

Bright, Fixed Aperture

The 150-400mm IS PRO provides a bright F4.5 aperture across the entire zoom range up to 800mm. The built-in 1.25x teleconverter boosts your focal reach to 1000mm with an F5.6 aperture. The Lens uses leading-edge optical technologies to reduce color fringing and flares and ensure edge-to-edge sharpness significantly. There are 28 glass elements arranged in 18 groups, including a large-diameter EDA lens and 4 Super ED lenses. Advanced Z Coating Nano minimizes ghosts and flares to deliver the exceptional image quality that M.Zuiko lenses are known for worldwide.

Built-In Teleconverter

Engage the 150-400mm IS PRO's built-in 1.25x teleconverter to extend the focal range to 1000mm (35mm equivalent). Add optional M.Zuiko teleconverters to provide a maximum equivalent focal range of 750-2000mm. With the M.Zuiko lens system, you'll enjoy unprecedented handheld telephoto reach.

From Telephoto To Macro

Sure, it's a distance-erasing ultra-zoom lens. But it also doubles as a lens for macro shooting. Don't want to get too close to your macro subject? Enjoy a 4-foot shooting distance throughout the zoom range with a 35mm equivalent maximum image magnification of x0.57. Use the 1.25x teleconverter to raise your magnification to x0.71 to capture spectacular detail on an insect or flower.

Focus Stacking Support

The 150-400mm IS PRO Lens supports focus stacking in compatible cameras to create composite images with a crisp emphasis from front to back.

TECH SPECS

Lens Construction

• Lens configuration: 28 elements / 18 groups
• Maximum image magnification: 0.13x (wide) / 0.29x (tele) - (equiv. 35mm): 0.25 x (wide) / 0.57 x (tele)
• The angle of view: 8.2 - 3.1°
• Focusing method: High-speed Imager AF (MSC)
• The angle of view (with built-in teleconverter): 6.6 - 2.5° (with built-in teleconverter applied)
• Closest focusing distance: 1.3m (across the entire zoom range, even with built-in teleconverter applied)
• Lens mechanism: Inner zoom, inner focus system
• Minimum field size: 139.5 x 104.8mm (wide) ----- 60.7 x 45.6mm (Tele)
• ED lens elements: 2 / 4 Super ED
• Aspherical ED element: 1
• HR elements: 2

Focal Length

• Focal length: 150 - 400mm ----- 187.5 - 500mm (with built-in teleconverter applied)
• Focal length (Equiv. 35mm): 300 - 800mm ----- 375 - 1000mm (with built-in teleconverter applied)

Aperture

• Maximum aperture: F4.5 / F5.6 (with built-in teleconverter applied)
• Minimum aperture: F22 / F29 (with built-in teleconverter used)
• Number of aperture blades: 9 Circular aperture diaphragm for natural background blurring

Image Stabiliser

• Modes: Two-dimensional, vertical or horizontal activation
• Effective Compensation Range: Up to 8 EV steps* 5-axis Sync IS ----- Up to 4.5 EV steps Lens IS
• Note: * According to CIPA standards. When attached to OM-D E-M1X, with yaw and pitch applied to the camera, half-press IS is set to Off, and the focal length is set to 150mm. (without built-in teleconverter)
• Type: Lens shift

Pro Features

• Dust, splash & freezeproof: Available
• Note: According to IP53

Converter Combinations

• Built-in Teleconverter: None
• Maximum image magnification: 0.22 (wide) / 0.50 x (tele) ----- 0.44 x / 1.01 x (Equiv. 35mm)
• Minimum field size: 111.6 x 83.9mm (wide) (with built-in teleconverter applied)
• Minimum field size (tele): 48.6 x 36.5 (tele) (with built-in teleconverter applied)
• MC-14:
• Maximum image magnification: 0.22 x (wide) / 0.50 x (tele) - (equiv. 35mm): 0.44 x / 1.01 x (equiv. 35mm)
• Closest focusing distance: 1.3m (across the entire zoom range, even with built-in teleconverter applied)
• Minimum field size: 79.1 x 59.4mm (wide) ----- 34.3 x 25.8mm (Tele)
• MC-20
• Maximum image magnification: 0.31 x (wide) / 0.71 x (tele) ----- 0.62 x / 1.43x (equiv. 35mm)
• Closest focusing distance: 1.3m (across the entire zoom range, even with built-in teleconverter applied)
• Minimum field size: 55.9 x 42.0mm (wide) ----- 24.3 x 18.2mm (Tele)
• Effective Compensation Range: Up to 7 EV steps* (5-axis Sync IS)
• Note: * According to CIPA standards. When attached to OM-D E-M1X, with yaw and pitch applied to the camera, half-press IS is set to Off, and the focal length is set to 300mm. (without built-inteleconverter)

Dimensions / Weight

• Diameter: 115.8mm (greatest dimension)
• Length: 314.3mm
• Filter diamater: 95mm
• Weight: 1.875kg (without Lens Cap, Lens Rear Cap, and Lens Hood)

Compatibility

• Compatible to Tele Converter MC-14: Yes
• Compatible to Tele Converter MC-20: Yes
• Operates with 5-axis Sync IS: Yes
• Compatible with 50fps: Yes

Cover / Cap

• Lens Cap: LC-115
• Lens Hood: LH-115
