Type
Single-lens reflex digital camera
Lens Mount
Nikon F bayonet mount
Picture Angle
Nikon DX format
Effective Pixels
24.1 million
Sensor Size
23.5mm x 15.6mm
Image Sensor Format
DX
Image Sensor Type
CMOS
Total Pixels
24.71 million
Dust-reduction system
Image sensor cleaning
Dust-Off Reference Photo
Yes
Image Area (pixels)
DX-format
(L) 6,000 x 4,000
(M) 4,494 x 3,000
(S) 2,992 x 2,000
1.3X Crop Mode
(L) 4,800 x 3,200 (13.5 MP)
(M) 3,600 x 2,400 (8.6 MP)
(S) 2,400 x 1,600 (3.8 MP)
Photographs In Movie Live View (16:9)
(L) 6,000 x 3,368 (20.2 MP)
(M) 4,496 x 2,528 (11.4 MP)
(S) 2,992 x 1,680 (5.0 MP)
Photographs Taken In Movie Live View Using The 1.3X Crop (16:9)
(L) 4,800 x 2,696 (12.9 MP)
(M) 3,600 x 2,024 (7.3 MP)
(S) 2,400 x 1,344 (3.2 MP)
File Format Still Images
JPEG: JPEG-Baseline Compliant with fine (approx 1:4), Normal (approx 1:8) or Basic (approx 1:16) Compression
NEF (RAW) + JPEG: Single Photograph Recorded in both NEF (RAW) and JPEG Formats
NEF (RAW): Lossless compressed, compressed 12 or 14 bit
Picture Control
Landscape
Monochrome
Neutral
Portrait
Standard
User-customizable Settings
Vivid
Storage Media
SD
SDHC
SDXC
Card Slot
2 Secure Digital (SD)
File System
Compliant with DCF (Design Rule for Camera File System) 2.0
DPOF (Digital Print Order Format)
EXIF 2.3 (Exchangeable Image File Format for Digital Still Cameras)
PictBridge
Viewfinder
Eye-level Pentaprism Single-Lens Reflex Viewfinder
Viewfinder Frame Coverage
100% Horizontal
100% Vertical Approx.
Viewfinder Magnification
0.94x Approx.
Viewfinder Eyepoint
19.5mm (-1.0m_)
Viewfinder Diopter Adjustment
-2.0 to +1.0m_
Focusing Screen
Type B BriteView Clear Matte Mark II screen
Reflex Mirror
Quick-return type
Lens Aperture
Instant-return type
Depth-of-field Control
Yes
Lens Compatibility at a Glance***
AF-S or AF lenses fully compatible
Metering with AI lenses
Compatible Lenses
AF NIKKOR, including type G and D lenses (some restrictions apply to PC Micro-NIKKOR lenses and DX lenses.
AI-P NIKKOR lenses, and non-CPU AI lenses (exposure modes A and M only)
Electronic rangefinder can be used with lenses that have a maximum aperture of f/5.6 or faster (the electronic rangefinder supports the center 1 focus point with lenses that have a maximum aperture of f/8 or faster).
IX NIKKOR lenses, lenses for the F3AF, and non-AI lenses cannot be used.
Shutter type
Electronically controlled vertical-travel focal-plane
Shutter Speed
1/8000 to 30 sec. in steps of 1/3 or 1/2 EV
Bulb
Fastest Shutter Speed
1/8000 sec.
Slowest Shutter Speed
30 sec.
Flash Sync Speed
Up to 1/250 sec.
Synchronizes with shutter at 1/320 s or slower
Bulb Shutter Setting
Yes
Shutter Release Modes
Continuous low-speed [CL] mode; 1-6 frames per second
Continuous high-speed [CH] mode; 6 frames per second
Interval timer photography supported
Mirror-up [Mup] mode
Quiet Shutter Release
Self-timer mode
Single-frame [S] mode
Continuous Shooting Options
DX-format
CH: Up to 6 frames per second
CL: Up to 1-6 frames per second
1.3X Crop Mode
CH: Up to 7 frames per second
CL: Up to 1-6 frames per second
Top Continuous Shooting Speed at full resolution
6 frames per second
Self-timer
2, 5, 10, 20 sec.; 1 to 9 exposures Timer duration electronically controlled
Exposure Metering System
TTL exposure metering using 2,016-pixel RGB sensor
Metering Method
Center-weighted: Weight of 75% given to 8mm circle in center of frame
Matrix: 3D color matrix metering II (type G and D lenses); color matrix metering II (other CPU lenses)
Spot: Meters 3.5mm circle (about 2.5% of frame) centered on selected focus point
Metering Range
0 to 20 EV (3D color matrix or center-weighted metering)
2 to 20 EV (Spot metering at ISO 100 equivalent, f/1.4 lens at 20_C/68_F)
Exposure Meter Coupling
CPU
AI
Exposure Modes
Aperture-Priority (A)
Manual (M)
Programmed auto with flexible program (P)
Shutter-Priority Auto (S)
Scene Modes
Autumn Colors
Beach / Snow
Blossom
Candlelight
Child
Close-up
Dusk / Dawn
Food
Landscape
Night Landscape
Night Portrait
Party / Indoor
Pet Portrait
Portrait
Sports
Sunset
Exposure Compensation
5 EV in increments of 1/3 or 1/2 EV
Exposure Bracketing
2 to 5 frames in steps of 1/3, 1/2, 2/3, 1, 2, or 3 EV
Exposure Lock
Yes
Mirror Lock Up
Yes
ISO Sensitivity
ISO 100 - 6400
Hi-1 (ISO 12,800)
Hi-2 (ISO 25,600)
Lowest Standard ISO Sensitivity
100
Highest Standard ISO Sensitivity
6400
Highest Expanded ISO Sensitivity
Hi-2 (ISO 25,600 equivalent)
Expanded ISO Sensitivity Options
Hi-1 (ISO-12,800 equivalent)
Hi-2 (ISO 25600 equivalent)
Long Exposure Noise Reduction
Yes
High ISO Noise Reduction
Low
Normal
High
Off
Active D-Lighting
Auto
Extra High
High
Normal
Low
Off
D-Lighting Bracketing
2-3 frames
2 frames using selected value for one frame or 3 frames using preset values for all frames
Single-point AF Mode
Yes
Dynamic AF Mode
Number of AF points: 9, 21, 51 and 51 (3D-tracking)
Auto-area AF Mode
Yes
Autofocus System
Nikon Multi-CAM 3500DX autofocus sensor module with TTL phase detection
Detection Range
-2 to 19 EV (ISO 100, 68_F/20_C)
Lens Servo
Autofocus (AF): Single-servo AF (AF-S); Continuous-servo AF (AF-C); auto AF-S/AF-C selection (AF-A); predictive focus tracking activated automatically according to subject status
Manual focus (MF): Electronic rangefinder can be used
Focus Point
Can be selected from 51 or 11 focus points
AF-area mode
9, 21 or 51 point Dynamic-area AF
