Gates Sony FX6 Underwater Housing Prime Kit

Prime Package Includes:

• Gates Sony FX6 Housing,
• SP60 Glass Port,
• SPR60-200,
• Seal Check Lite,
• Tool Kit,
• Spares Kit,
• LGD Kit

The FX6 Underwater Housing is, in every respect, what you've come to expect from Gates: simplicity and durability yet easy setup and operation; full camera control; perfect buoyancy/trim; field serviceability; Seal Check "know before you go" peace of mind; and Gates' exclusive Lens Gear Drive system supports a vast array of lenses—mirrorless, cinema, anamorphic, and more.

Gates FX6 Housing goes further with an easy-to-see angled rear LCD window and a side control window for a clear view of camera functions accessible in water. Available FX6 useful options include surface SDI video, a top-mounted External Monitor, and topside camera/lens control via Sony RM-30P + Gates MultiCon surface tether system. Perhaps most importantly, Gates FX6 Housing is an affordable, performance-to-price workhorse.

Protecting your ROI? FX6 Housing carries forward Gates' system-wide, plug-and-play Precision Port and Stackable Port Ring system. Gates' legendary customer support is, naturally, behind the FX6 Housing. Gates professionals know that failure is not an option. They know: Don't take a chance—take a GATES!

Key Features

Compact, Travelable.

Among its many strengths, the FX6 Housing is well-fitted to the Sony FX6 camera. This means a small, low-profile system that's easy to manage above and below water.

Fully Integrated Monitor

Comfortable 15° view angle and daylight-viewable, Gates FX6 has an easy-to-see rear view window to the Sony FX6 LCD (included with FX6 camera).

Seal Check Lite

Don't rely on a binary red/green light to keep your precious camera safe. Seal Check Lite's precision vacuum gauge puts you in charge of the go / no-go decision. When unexpected things happen (and they do happen), Seal Check Lite is a troubleshooter, locating leaks and quickly returning to action.

Extensive Lens Support

Gates' unique Lens Gear Drive system is versatile and adaptable to mirrorless, cinema, anamorphic, and specialized glass (e.g., Laowa Periprobe).

Full Camera Control You Can See

The FX6 side control window provides a clear view of all key camera functions accessible underwater.

Clean, Uncomplicated, Reliable Design

A Gates mantra: simplicity = reliability. Convenience details are nice, but not at the expense of function, purpose, and results.

Adjustable Buoyancy / Trim

The Gates trim system lets you establish perfect buoyancy and balance underwater, which is key to stable, fluid shots.

2-Year Warranty.

Legendary factory direct support.

Gates is synonymous with reliability and support, and only Gates offers a 2-year, renewable warranty on all housings.

Specifications

• Controls:
• 3x Direct Mechanical Lens Gear Drives
• POWER switch
• REC Start / Stop
• Variable ND Filter
• ND Auto
• Multi-Function Dial
• Multi-Function Dial Select
• Push Auto Focus
• ISO / GAIN Button
• WHT BAL Button
• SHUTTER Button
• MENU Button
• CANCEL / BACK Button
• IRIS Button
• DISPLAY
• S&Q / ASSIGN 1 Button
• ASSIGN 2 Button
• ASSIGN 3 Button
• WB SET
• MONITOR Buttons
• PEAKING
• ZEBRA
• Assign #9 Button
• Dimensions: Dimensional Drawing TBD
• Construction:
• Machined Aluminum, Type III Hard Anodized finish
• Stainless steel hardware
• Depth Rating: 300 feet / 92 meters
• Weight in Water: Adjustable Buoyancy / Trim
• Weight in Air:
• Variable depending on system setup
• TBA typical housing setup
• Warranty: 2 Years Renewable.
