Delkin CFast 2.0 Memory Card - 128 GB
Highlights
- Compliant with CFast 1.1 Standard
- SATA II 3 Gb/s (Backward compatible to SATA I)
- 2 64GB SLC, 8 128GB MLC
- -40 to 85_C Operating Temp
- Read / Write Speeds up to 125/95 MB/s
For embedded platforms which have used CompactFlash as a boot drive or other storage medium, and now face a migration from PATA to SATA due to a processor change, CFast is a logical choice for new designs. CFast has all of the mechanical advantages of CF small, rugged, cased, easily customizable with the added benefits of the SATA interface. CFast is governed by the CompactFlash Association (www.compactflash.org), with mechanical dimensions virtually identical to CF, as the only differences are thickness (3.6mm for CFast vs. 3.3mm for CF) and the 24-pin SATA connector in place of the 50-pin CF connector. Delkin offers a range of industrial temperature CFast capacities in both SLC and MLC flash, to provide the best solution for a given application, whether write intensive requiring high endurance or cost sensitive.
Delkin controls bills of materials down to the flash, controller and firmware version, so once a part number is qualified, the same configuration will be delivered until its EOL date. And recognizing the value of strong life cycle management, Delkin provides advance notification when a part must eventually be discontinued, offering last time buy opportunities and replacement parts for qualification.
Delkin also acknowledges that an off-the-shelf part may not always be the best fit, and provides many customization options ranging from custom labels, serialization, content and image loading, conformal coating, custom testing, mechanical ruggedization, even a complete custom design. Contact us to ask how we can customize a drive for your application.
Features
- Compliant with CFast 1.0 Standard, SATA replacement for CompactFlash cards
- Compliant with SATA Revision 2.6 specification (3 Gbps / 1.5 Gbps)
- Fully compatible with ATA-7; Supports transfer modes PIO 0-4, MDMA 0-2 and UDMA 0-6
- Supports ATA Security Erase
- Advanced wear-leveling and ECC
- Rugged, industrial embedded drive with under-fill for critical components
- SMART enabled for monitoring performance and managing product life in application
- Protection against data and firmware corruption during power loss
- Customizable conformal coating, labeling, content loading, additional mechanical ruggedization, etc.
- Compliant with European Union Directive 2011/65/EU (RoHS)
Specs:
- Environment
- Operating Temp: -40 to +85_C
- Storage Temp: -50 to +100_C
- Shock: 10G, 11msec Sawtooth Waveform
- Vibration :7.7GRMS
- 20Hz 1000Hz @ 0.04 G2/Hz,
- 1000Hz 2000Hz @ 0.01 G2/Hz
- Reliability / Endurance
- TBW
- MTBF
- > 3 million hours (0 to +25_C)
- > 200,000 hours (60_C)
- Capacity Range
- SLC: 2GB 64GB
- MLC: 8GB 128GB
- Performance
- SLC
- Sequential Read up to 120MB/s
- Sequential Write up to 90MB/s
- MLC
- Sequential Read up to 120MB/s
- Sequential Write up to 40MB/s
